Autmog

40 Clipless Click Pen x KVR Finishing - 6Al-4V Titanium - 6061 Aluminum Mechanism - Round Nose - Grip Lines - Pilot G2

Regular price $247.00 CAD
Regular price Sale price $247.00 CAD
Shipping calculated at checkout.

Please note there is a limit of one item per customer for this release. Short run anodized design dark blue to blue fade by KVR Finishing.

Super sleek round nose design for the Pilot G2 format refill. Includes an o-ring bumper that softens the return kickback to a nice thump. 0.40" body diameter with the same diameter mechanism. Includes all of the improvements from previous versions plus a few new ones. Retract mechanism is easier to push. The spring rate is more preferable for a slightly larger diameter mechanism.

The 6061 Aluminum clipless mechanism, is bright and smooth. There is a tight fit between the button stanchion and the mechanism body making it more resistant to binding from pressing the button on an angle. Improved mechanism button chamber features making button action even smoother. There is now a single detent track that improves the button bias depending on which side of the button is facing forward. Proper allowance for the refill and spring and mechanism is able to operate very smoothly, without the rough action of the refill and spring translating to the button.

Made out of the tough and hard solid bar stock 6Al-4V Grade 5 Titanium and the bright 6061 Aluminum for the mechanism. A single 0.40" (10.16mm) diameter grip, rounded nose section and grip grooves. The mechanism comes equipped with stainless steel balls. Tip details are extremely tight with a small land between the refill, and the conical section.

Minimal and clean design coupled with the Pilot G2 0.7mm refill.

Pinch the mechanism between your index finger and thumb to retract the mechanism with a satisfying snap. The click and return is very solid and super satisfying. Tolerances, fit and finish for the mechanism are very close.

Tip point details are very clean with an excellent tight fitting 2.5mm diameter bore and a tolerance of just 25 micron to keep the refill tip exactly in place.

Higbee thread start to the pen body to make the thread action for replacing the refill better.

This version is 5.34" (135.64 mm) long, 0.40" (10.16mm) in diameter, and 29.0g (1.02oz)
